Model: YZ6745/YZ6745T (Trinocular)
Accessories: Standard/Optional
YZ6745 Series zoom stereo microscope , fully coated optial system sharp and clear images with extremely good flatness and contrast. It is characterized by brand-new optical design, the best reprduction and true color image. With their large zoom rang and long-working distance. These are ideal for high-magnification, high-resolution observation in biological research, precision-oriented semi-conductor, industries.
1. Non-flash in focusing course, large depth of fields
2. It is characterized by brand-new optical design, the best reproduction and true color image
3. Total magnification extend to: 3.4X～270X
4. Standard working distance 105mm, maximum extend to 177mm
5. Diopter adjustment range ±5 diopter
6. It has many optional stands and attachments
Model | YZ6745 | YZ6745T | ||||||||
Eyepiece | Standard | Auxiliary objective 0.5X | Auxiliary objective 1.5X | Auxiliary objective 2X | ● | ● | ||||
Working distance 105mm | Working distance 177mm | Working distance 47mm | Working distance 26mm | ● | ● | |||||
Mag. | Field of view | Mag. | Field of view | Mag. | Field of view | Mag. | Field of view | ● | ● | |
10X/22mm | 6.7X | 32.8 | 3.4X | 65.7 | 10.1X | 21.9 | 13.4X | 16.4 | ||
45.0X | 4.9 | 22.5X | 9.8 | 67.5X | 3.3 | 90.0X | 2.4 | |||
15X/16mm | 10.1X | 23.9 | 5.0X | 47.8 | 15.1X | 15.9 | 20.1X | 11.9 | ||
67.5X | 3.6 | 33.8X | 7.1 | 101.3X | 2.4 | 135X | 1.8 | |||
20X/12mm | 13.4X | 17.9 | 6.7X | 38.5 | 20.1X | 11.9 | 26.8X | 9.0 | ||
90.0X | 2.7 | 45.0X | 5.3 | 135.0X | 1.8 | 180.0X | 1.3 | |||
25X/9mm | 16.8X | 13.4 | 8.4X | 26.9 | 25.1X | 9.0 | 33.5X | 6.7 | ||
112.5X | 2.0 | 56.3X | 4.0 | 168.8X | 1.3 | 225X | 1.0 | |||
30X/8mm | 20.1X | 11.9 | 10.1X | 23.8 | 30.2X | 7.9 | 40.2X | 6.0 | ||
135.0X | 1.8 | 67.5X | 3.6 | 202.5X | 1.2 | 270X | 0.9 | |||
Total Mag. | Standard setting：6.7X-45X，Option eyepiece and auxiliary objective extend to：3.35X-270X continuous zoom | ● | ● | |||||||
Eyepiece | Standard setting：10X/22mm，Large field of view, wide angle, high eye point, providing convenience for observers wearing glasses | ● | ● | |||||||
Optional eyepiece | 10X/22mm，15X/16mm，20X/12mm，25X/9mm，30X/8mm | ● | ● | |||||||
Obseration head | 45°inclined、360°rotated，interpupillary distance adjustment range 54-75mm；bilateral diopter adjustment range±5 | ● | ● | |||||||
Compensation free binocular | ● | ◎ | ||||||||
Compensation free trinocular，split ratio 50%/50%、0/100% | ◎ | ● | ||||||||
Objective | Standard setting：0.67X-4.5X continuous zoom，zoom ratio 6.7:1，make sure the image is in focus | ● | ● | |||||||
Microscopic photographic setting | Can be connected to microscope camera, SLR camera or digital camera | ◎ | ● | |||||||
Auxiliary objective | Optional 0.3X，0.5X，0.7X，0.75X，1.5X，2X | ● | ● | |||||||
Focus adjustment holder | A1 Adjustable tightness of handwheel of focus bracket、Lifting range 50mm | ● | ● | |||||||
Base | Optional for the other base | ● | ● | |||||||
Light source | Optional various fluorescent lamp、LED ring light | ● | ● | |||||||
